Golf Cart Battery
General Features
1.Brand new&grade A deep cycle LiFePO4 cell
2. Simple to install and easy to get started
3. Bluetooth to check battery status
4. Compatible with mainstream vehicle controller
5. High discharge rate, long life span
6. parallel-solution for different compartment
Specifications
Item | General Parameter |
Battery Model | ELT384105G | ELT512100G | ELT512160G | ELT768105G |
Energy | 4032Wh | 5376Wh | 8192Wh | 8064Wh |
Rated Capacity | 105Ah | 105Ah | 160Ah | 105Ah |
Nominal Voltage | 38.4V | 51.2V | 51.2V | 76.8V |
Cut-Off Voltage | 30V | 40V | 40V | 60V |
Charging Voltage | 43.8V | 58.4V | 58.4V | 87.6V |
Standard Charge | CC@0.2C to 43.8V/58.4V/58.4V/87.6V,then CV till current to 0.05C |
Max. Continuous Charge Current | 100A | 100A | 160A | 100A |
Max. Continuous Discharge Current | 100A | 200A | 200A | 100A |
Pulse discharge current | 200A | 400A | 400A | 315A |
Communication | CAN / RS485 |
Operation Temperature | Charge: 0~55℃ |
Discharge: | -20~65℃ |
Storage Temperature | 0~45℃ |
Bluetooth Function | Yes |
LCD Display | Optional |
IP Grade IP67 | IP67 |
Certificates | UN38.3 / MSDS /CE |
Dimension(L*W*H) | 385*338*245 mm | 509*334*230mm | 779*339*230mm | 740*320*246 mm |
Net Weight | 34kg | 45kg | 68kg | 72kg |
