All In One-SHENZHEN BINENG POWER TECHNOLOGY CO.,LTD

All In One

Online Inquiry

Previous Next

Details

Model	BPA512-10	BPA512-15	BPA512-20	BPA512-25	BPA512-30
Inverter parameter
Rated power	10kW
AC rated voltage	230VAC
Selectable voltage range	90-280VAC
Frequency range	50Hz/60Hz
AC voltage	230VAC±5%
Efficiency	93.5%
Transfer time	10ms
Waveform	Sine wave
Rated battery voltage	51.2V
Battery voltage range	43.2-57.6V
Compatible battery type	Lithium
Max.PV array open circuit voltage	500VDC
Max.PV array power	11kW
MPPT range@Operating voltage	90-450VDC
Max.charge current	150A
Battery parameter
Rated capacity	10 kWh	15 kWh	20 kWh	25 kWh	30 kWh
Nominal voltage	51.2V
Discharge voltage range	43.2-57.6V
Charging current	0.5C@25℃
Max.charging current	1C@25℃
Max.discharge current	1C@25℃
Max.power output	10240Wh	15360Wh	20480Wh	25600Wh	30720Wh
Depth of discharge DOD	0.9
Communication Interface	RS485/RS232/CAN
Cycles	25±2℃,0.5C/0.5C,EOL80%≥6000
Working Temp.Range	Charge:0℃~50℃ Discharge:-10℃~60℃
