Lead Acid Battery Replacement
The LiFePO4 battery has series the same standard structural specifications as the lead-acid battery, comparatively having the advantages of high safety, good reliability, long cycle life, good high/low-temperature performance, etc. With these unique advantages, it has been used in a wide range of application scenarios, such as RV, sightseeing carts, marine, scooters, tricycles, emergency lighting, and security monitoring. The LiFePO4 battery is an ideal drop-in replacement solution for the traditional lead-acid batteries used on the existing market.
Features
Smart BMS with over-current, over-charge, over-discharge, short circuit, (optional)Bluetooth. low-temp cut-off, self-heating
Grade A LiFePO4 cELLS
Support expansion for 4 series and 4 parallel (4P4S)
10 times longer life-span than traditional lead acid battery
30% lighter than lead acid battery
≥2000cycles@100% DOD，up to 5000cycles @80% DOD
Operation Temperature
Charge 0°C 〜50°C(32°F〜122°F)
Discharge -20°C~60oC(-4°F~140oF)
Storage -10°C 〜50°C(-14°F 〜122°F)
Low temp cut off protection (Charge) 0°C ± 4°C (32°F ± 39.2°F)
Low temp cut off protection (Discharge) -20°C±4°C(~4°F±39.2°F)
Why choose us
Widely used
RV
Camping
Boat and Fishing
Solar&Wind system
Specifications
| Model NO. | BP-LFP-12100 | BP-LFP-12200 | BP-LFP-12300 | BP-LFP-12460 | BP-LFP-24100 | BP-LFP-24200 |
| LiFePo4 Battery | 12.8V 100Ah | 12.8V 200Ah | 12.8V 300Ah | 12.8V 460Ah | 25.6V 100Ah | 25.6V 200Ah |
| Nominal Voltage | 12.8V | 12.8V | 12.8V | 12.8V | 25.6V | 25.6V |
| Charge Voltage | 14.2V-14.6V | 14.2V-14.6V | 14.2V-14.6V | 14.2V-14.6V | 28.4V-29.2V | 28.4V-29.2V |
| Weight | 11KG/24.2LB | 22KG/48.5LB | 26.5KG/58.42LB | 104.7LBS/47.5KG | 20KG/44.09LB | 36.6KG/80 .69LBs |
| Energy | 1280Wh | 2560Wh | 3840Wh | 5888Wh | 2560Wh | 5120Wh |
| Max Continuous Charging Current | 100A | 200A | 200A | 120A | 100A | 200A |
| Max Continuous Discharging Current | 100A | 200A | 200A | 250A | 100A | 200A |
| Recommend Charge Current | 20A(0.2C) | 40A(0.2C) | 60A(0.2C) | 92A(0 .2C) | 20A(0.2C) | 40A(0 .2C) |
| Max Load/Inverter Power | 1280W | 2560W | 2560W | 3200W | 2560W | 5120W |
| Waterproof Class | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Terminal Type | M8 | M8 | M8 | M8 | M8 | M8 |
| Demension | 329x172x214mm | 522x240×218mm | 520x269x220mm | 480x275x250mm | 522x240x218mm | 520x269 x220mm |
| 12.95*6.77*8.42inch | 20.55*9.44*8.58inch | 20.47*10.59*8.66inch | 18.9x10.82x9.84in | 20.55*9.44*8.58inch | 20.47*10.59*8.66inch |
